型號 |
最大受力（N.m） |
螺母對邊 |
驅(qū)動軸 |
厚度 |
重量 |
適用齒桶直徑 |
傳動比 |
|
TDP02 |
3000 |
19-60 |
3/4或1 |
32 |
3.2 |
76 |
1：1或定制 |
|
TDP04 |
6000 |
34-80 |
1或1-1/2 |
42 |
4.3 |
88/96 |
1：1或定制 |
|
TDP08 |
10000 |
41-95 |
1-1/2 |
53 |
5.3 |
122 |
1：1或定制 |
|
TDP14 |
18000 |
50-105 |
1-1/2 |
64 |
6.4 |
139 |
1：1或定制 |
|
上述重量不包含特殊反力臂和特殊定制的傳動比 |
|||||||
詳細(xì)尺寸
|
TDP02 |
TDP04 |
TDP08 |
TDP12 |
||||||||
|
螺母對邊 |
R |
G |
螺母對邊 |
R |
G |
工作頭 |
R |
G |
工作頭 |
R |
G |
|
TDP02-19 |
27 |
16 |
TDP04-34 |
36 |
16 |
TDP08-41 |
46 |
22 |
1TDP04-50 |
60 |
31 |
|
TDP02-22 |
27 |
14 |
TDP04-36 |
36 |
15 |
TDP08-46 |
46 |
19 |
1TDP04-55 |
60 |
28 |
|
TDP02-27 |
27 |
11 |
TDP04-41 |
39 |
15 |
TDP08-50 |
46 |
17 |
1TDP04-60 |
60 |
25 |
|
TDP02-30 |
29 |
12 |
TDP04-46 |
42 |
15 |
TDP08-55 |
50 |
18 |
1TDP04-65 |
60 |
22 |
|
TDP02-32 |
29 |
11 |
TDP04-50 |
44 |
15 |
TDP08-60 |
52 |
17 |
1TDP04-70 |
60 |
19 |
|
TDP02-34 |
31 |
11 |
TDP04-55 |
46 |
14 |
TDP08-65 |
55 |
17 |
1TDP04-75 |
63 |
19 |
|
TDP02-36 |
31 |
10 |
TDP04-60 |
50 |
15 |
TDP08-70 |
58 |
17 |
1TDP04-80 |
66 |
19 |
|
TDP02-41 |
34 |
10 |
TDP04-65 |
53 |
15 |
TDP08-75 |
60 |
17 |
1TDP04-85 |
69 |
19 |
|
TDP02-46 |
37 |
10 |
TDP04-70 |
56 |
15 |
TDP08-80 |
63 |
16 |
1TDP04-90 |
72 |
20 |
|
TDP02-50 |
40 |
11 |
TDP04-75 |
59 |
15 |
TDP08-85 |
66 |
16 |
1TDP04-95 |
74 |
19 |
|
TDP02-55 |
43 |
11 |
TDP04-80 |
61 |
15 |
TDP08-90 |
69 |
17 |
1TDP04-100 |
77 |
19 |
|
TDP02-60 |
46 |
11 |
|
|
|
TDP08-95 |
71 |
16 |
1TDP04-105 |
80 |
19 |
